MIST TUNNEL

Empowering Simplicity and Modularity to Next Level




TECHNICAL SPECIFICATIONS

  • Overall Size of Booth in mm : 2000 H x 1060W x 2000 L /2000 H x 1060W x 3000 L
  • Fully Automatic Sensor Based Activation
  • Fully Transparent
  • High Pressure Misting Pump – 150 Bars
  • High Performance Nozzles, Diameter : 0.3mm
  • Motor 220V AC single phase
  • High pressure tubing P.E. Polyflex nylon
  • Low Power Consumption
  • System won’t wet You
  • Water resistance Aluminium Modular Structure
  • Continuous Movement of People.
  • Settable Control Panel
  • Strong, sturdy walkway
  • Panel box with IR sensors and timer
  • Allocated Space for Advertisement Panel

Customer Scope :

  • Single Phase Power.
  • Tank of minimum 200 Litres.
  • Liquid for Mist.
  • Options of available media will be sent on release of purchase order.
  • Approx. consumption per Hour is 22 litres with continuous run for 2000mm and 42 litres for 3000mm.
